802 D4 SATIN

旗舰型800钻石系列落地式扬声器

Diamond Tweeter
Solid body Tweeter-on-Top
Continuum™ Cone FST
Anti-Resonance Plug
Biomimetic Suspension
Turbine™ Head
Matrix™
Aerofoil™ Cone Bass Units
Flowport™

选择 Quality

选择外观：

Black White ROSENUT WALNUT

Black

查找零售商

802 D4 SATIN

802 D4 SATIN

802 D4 SATIN

详细信息和规格

Size & weight

Net weight 88.10kg (194.2 lb)
Dimensions Height: 1218mm (48 in)
Width: 413mm (16.3 in)
Depth: 602mm (23.7 in)

Finishes

Cabinet finishes Gloss Black
White
Satin Rosenut
Satin Walnut
Grille finishes Black
Grey
Black
Grey

Technical details

Technical features Diamond tweeter
Solid body Tweeter-on-Top
Continuum™ cone FST
Anti-Resonance plug
Biomimetic Suspension
Turbine™ Head
Matrix™
Aerofoil™ cone bass units
Flowport
Description 3-way vented-box system
Drive units 1x ø25mm (1in) Diamond dome high-frequency
1x ø150mm (6in) Continuum cone FST midrange
2x ø200mm (8in) Aerofoil cone bass units
Frequency range 14Hz to 35kHz
Frequency response 17Hz to 28kHz (+/-3dB from reference axis)
Sensitivity 90dB (on axis at 2.83Vrms at 1m)
Harmonic distortion 2nd and 3rd harmonics (90dB,1m on axis)
<1% 70Hz – 20kHz
<0.3% 100Hz – 20kHz
Nominal impedance 8Ω (minimum 3.0Ω)
Recommended amplifier power 50W – 500W into 8Ω on unclipped programme
Max recommended cable impedance 0.1Ω
