Size & weight
- Net weight 18.65kg (41.12 lb)
-
Dimensions
Height: 325mm (12.8in) not including feet or spikes
337mm (13.3in) including feet
353mm (13.9in) including spikes
Width: 325mm (12.8in)
Depth: 348mm (13.68in) not including grilles
375mm (14.8in) including grilles and controls
Technical Details
- Drive units ø250mm (10 in) Paper / Aramid fibre cone long-throw
- Frequency response ±3dB 25Hz – 40 / 140Hz adjustable (EQ at A)
-
Technical features
Input level (line in)
Input level (speaker in)
Low-pass filter frequency (line in only)
Low-pass filter bypass
Bass extension
Bass roll-off alignment
Auto sense on / standby
Phase switch - Description Active closed-box subwoofer system
- Frequency range -6dB at 18Hz and 25 / 140Hz adjustable (EQ at A)
-
Inputs
Line in (RCA Phono)
Speaker in (Binding post)
12v trigger (3.5mm jack)
Low-pass filter
Active 4th-order, variable cut-off frequency - Amplifier power output 500W
- Power consumption 98W / 1W standby
- Input impedance 33kΩ
- Signal / Noise >80dB
-
Bass extension
-6dB at 18Hz (position A)
-6dB at 23Hz (position B)
-6dB at 28Hz (position C)
Finishes
-
Cabinet finishes
Black
White -
Grille finishes
Black
Grey
