Size & weight
- Net weight 9.66kg (21.3 lb)
-
Dimensions
Height: 165 mm (6.5 in) cabinet only
Width: 477 mm (18.8 in) Cabinet only
Depth: 266 mm (10.5 in) Cabinet only
302 mm (11.9 in) including grille and terminals
Technical details
-
Drive units
1x ø25mm (1 in) Decoupled Carbon Dome high-frequency
2x ø130mm (5 in) Continuum cone bass / midrange - Frequency range 48Hz - 33kHz
- Frequency response 70Hz - 28kHz ±3dB
-
Harmonic distortion
2nd and 3rd harmonics (90dB, 1m on axis)
<1% 100Hz - 22kHz
<0.5% 200Hz - 22kHz
- Nominal impedance 8Ω (minimum 4.3Ω)
- Recommended amplifier power 30W - 120W into 8Ω on unclipped programme
- Sensitivity 87dB spl (on axis at 2.83Vrms at 1m)
-
Technical features
Decoupled Carbon Dome tweeter
Continuum™ cone bass / midrange
Flowport™ - Description 2-way vented-box system
- Max recommended cable impedance 0.1Ω
Finishes
-
Cabinet finishes
Gloss Black
Satin White
Mocha -
Grille finishes
Black
Grey (Satin White only)
